Sehen Sie, wie die Multiphysik-Simulation in Forschung und Entwicklung eingesetzt wird
Ingenieure, Forscher und Wissenschaftler aus allen Branchen nutzen die Multiphysik-Simulation, um innovative Produktdesigns und -prozesse zu erforschen und zu entwickeln. Lassen Sie sich von Fachbeiträgen und Vorträgen inspirieren, die sie auf der COMSOL Conference präsentiert haben. Durchsuchen Sie die untenstehende Auswahl, verwenden Sie die Schnellsuche, um eine bestimmte Präsentation zu finden, oder filtern Sie nach einem bestimmten Anwendungsbereich.
Sehen Sie sich die Kollektion für die COMSOL Conference 2024 an
三元锂离子电池作为目前电动汽车的主流储能设备之一,其电化学性能与热性能引发诸多关注。锂离子电池的内部电化学特性和热特性对其性能有显著影响,但这些特性无法通过实验方法得到。本文基于多物理场耦合仿真软件COMSOL Multiphysics® 5.4,采用有限元方法,将电池电化学模型与热模型结合分析电池的电化学特性以及热行为。通过电化学模型和热模型原理,建立了30 Ah三元锂离子方形电池的三维电化学-三维热耦合模型。采用热传导模块建立了由电芯、正极和负极片组成的三维热模型,并覆盖电池硬壳,采用自由四面体法进行网格划分。基于该模型 ... Mehr lesen
Here we optimize the geometry: proof mass length Lm to total length L, thickness of the piezoelectric material (Tp) to total cantilever thickness (T) for obtaining the maximum stress distribution (Smax), output voltage (Vout) and power performance (Pout) of the unimorph Cantilever beam ... Mehr lesen
The proposed State of Charge (SOC) governed fast charging method for secondary lithium based batteries charges a battery many times faster than the normal Constant Current-Constant Voltage (CC-CV) charging and reduces the side-effects generally accompanied by various fast charging ... Mehr lesen
由于能源紧缺和环境污染的问题,电动汽车在近二十年来得到了快速迅猛的发展。动力电池作为电动汽车最为核心的部件之一,将影响到电动汽车未来的发展方向。如果能够对电池进行合理的建模与仿真,将会对电池的研究、设计和使用具有很好的指导意义。为了配合车用BMS算法开发,需要不同荷电态(SOC)、温度、脉冲时间下的内阻、极限电流/功率的MAP等数据。而MAP数据量过大,手动逐点仿真工作量太大,同时,极限电流/功率等需要查找,手动操作复杂。通过COMSOL与MATLAB联合仿真技术自动化获取数据,可以提高计算精度,减少人为测试量,减少开发成本。 ... Mehr lesen
The thermal behavior of lithium ion batteries could be investigated by efficient simulation method [1,2]. Here, we developed an electrochemical-lumped thermal analytical model to analyze the thermal response and heat breakdown of a pouch LiNi1/3Co1/3Mn1/3O2 battery (3Ah) under fast ... Mehr lesen
Abstract:The thermal behavior of lithium ion batteries could be investigated by efficient simulation method [1,2]. Here, we developed an electrochemical-lumped thermal analytical model to analyze the thermal response and heat breakdown of a pouch LiNi1/3Co1/3Mn1/3O2 battery (3Ah) under ... Mehr lesen
在电池包中,存在多个模组和电池串并联而会不断的积蓄热量,热量得不到及时的控制,导致电池组温度分布的不均匀性,引起电池寿命的减少和均衡性变差,同时电池安全也得不到保障,设计出高效且可靠的散热结构和方式尤为重要。 通过COMSOL Multiphysics 5.4软件中建立耦合的电池瞬态热模型,包括模型几何的构建,材料参数的导入以及网格剖分。电池的几何模型为原始几何模型,在COMSOL Multiphysics 5.4软件中的边界条设置均为默认,网格剖分采用物理场控制的四面体网格。在模型的输入部分主要为三块,分别为电池的发热功率随时间的变化曲线 ... Mehr lesen
The performance of Li-ion battery is known to be dependent on the thickness direction distribution of binder volume fraction. The distribution is determined by drying process of electrode ink, which contains large active material and small binder. With the aim of predicting binder ... Mehr lesen
随着电池单体向大尺寸,高比能量,以及快速充电的技术发展,电池的不均匀性也呈现增大的趋势。大倍率充电会造成电池较大的内外温差,甚至可能引发析锂或热失控。因此,在保证电池不析锂的前提下,开发更优的快充策略也应着重关注电池的内外温差。建立三维电化学-热耦合热模型(耦合电池接口以及固体传热接口),通过添加Event接口,进行不同充电策略的设置能够实现对电池内外温度进行仿真。3D电化学模型分为五个域(正负极多孔电极、隔膜,以及半片铜铝箔),3D热模型为真实结构的方形电池(极组与铝壳前后完全接触,左右不完全左右,空隙充满电解液域)。热源有三部分 ... Mehr lesen
Two Anode Surface processes are examined : Formation of Solid Electrolyte Interphase (SEI) and heating due to Shuttle Current. During charging, higher order sulfur species are reduced at the anode surface, while they are concurrently being oxidized at the cathode. This leads to the ... Mehr lesen
