Coupling Thermoelectromechanical problems
Posted 19.11.2013, 06:27 GMT-5 1 Reply
Please login with a confirmed email address before reporting spam
Hi All
I want to coupled three things, thermal +structural + electrical problems and solve them all together not separately. Any idea how to do it in COMSOL. I ave attached the coupled equations.
Thanks,
I want to coupled three things, thermal +structural + electrical problems and solve them all together not separately. Any idea how to do it in COMSOL. I ave attached the coupled equations.
Thanks,
Attachments:
1 Reply Last Post 21.11.2013, 02:30 GMT-5
Please login with a confirmed email address before reporting spam
Posted:
1 decade ago
Hi,
There are basically two approaches that you could use:
1. Build the model with one Piezoelectric Devices interface and one Heat Transfer in Solids interface. Then add the missing coupling terms using weak contributions. Maybe not all couplings are significant?
or
2. Create the whole fully coupled physics using the Physics builder.
Regards,
Henrik
There are basically two approaches that you could use:
1. Build the model with one Piezoelectric Devices interface and one Heat Transfer in Solids interface. Then add the missing coupling terms using weak contributions. Maybe not all couplings are significant?
or
2. Create the whole fully coupled physics using the Physics builder.
Regards,
Henrik
