Gold nanoshell simulation. Why the scattering curve is below zero?
Posted 05.04.2012, 10:48 GMT-4 RF & Microwave Engineering Version 3.5a, Version 4.2, Version 4.2a 2 Replies
Please login with a confirmed email address before reporting spam
I modified a model of Mie scattering off gold plasmonic nanopartical to simulate the gold nanoshell structure I found on comsol forum.
I just add a sphere inside the original particle and built a shell structure.
However, the scattering curve of this model turned to be always below zero, which is not physical.
Does anybody have ever met this problem?
In the picture I upload, the red curve is the scattering, and the blue one is the absorbency, and the green line is the extinction, which is the sum of scattering and absorbency.
Attachments:
Hello Jingmao Chi
Your Discussion has gone 30 days without a reply. If you still need help with COMSOL and have an on-subscription license, please visit our Support Center for help.
If you do not hold an on-subscription license, you may find an answer in another Discussion or in the Knowledge Base.
